High Torque & Powerful Output
• Speed range: 0–350 rpm, output power 150W
• Rated torque ≥3.5Nm, powerful performance
• Ideal for dense bone machining in hip joint surgery
High Precision & Low Noise
• No-load noise ≤65dB(A), quieter operation
• Radial runout ≤1mm for precise drilling
• Reduces vibration to improve surgical stability
Wide Clamping Range
• Chuck clamping range:1.0–8.1mm
• Compatible with various specifications of surgical drills
• Flexible for diverse hip surgical drilling requirements
Rechargeable Battery & Wide Compatibility
•Ni-MH battery: 1800mAh, 14.4V
• Wide charger input AC110–220V, 50–60Hz
• Interchangeable battery and charger with other power hosts of the series
Specifications
| Parameter | Description |
|---|---|
| Product Type | Battery Powered High Torque Hip Joint Drill |
| Model | XGZ‑DZ‑III |
| Application | Orthopaedic hip joint surgery |
| Power Supply | Ni-MH battery, 1800mAh, 14.4V |
| Sterilization Method | 134°C high‑temperature steam sterilization |
| Compatible Accessories | Drill bits, battery, charger and series orthopaedic attachments |
| Speed Range | 0-350 rpm |
| Output Power | 150W |
| Rated Torque | ≥3.5Nm |
| No-load Noise | ≤65dB(A) |
| Radial Runout | ≤1mm |
| Clamping Range | 1.0-8.1mm |
| Charger Input Voltage | AC110-220V, 50-60Hz |
