Product Introduction

The Pubic Symphysis Locking Plate is designed for fixation of pubic symphysis disruptions. Its threaded locking holes work with matching locking screws to form a rigid bone-screw-plate construct and provide angular stability.

The plate is anatomically contoured for the pubic symphysis region, with a low-profile design, rounded edges, and a polished surface to help minimize soft tissue irritation. The system is manufactured from TA3G pure titanium or TC4 titanium alloy for mechanical strength and biocompatibility.

Features

• 20° conical locking holes designed to provide angular stability with locking screws

• Sharp self-tapping screw tips for efficient screw insertion

• Anodized color surface treatment for easier identification of screws and plates

• Anatomically precontoured plate body with polished, rounded low-profile edges to help reduce soft tissue irritation

• Compatible with locking and cortical screws in different sizes

• Symmetrical and asymmetrical plate designs available for different anatomical requirements

Advantage

• Strong angular stability through the matching interface between the 20° conical locking holes and screw threads

• Smooth, rounded, polished surfaces help minimize soft tissue irritation and tissue adhesion

• Plate fixation does not require compression of the plate against the bone, helping preserve the periosteal blood supply

• Versatile application for both primary and revision fixation procedures

• Asymmetrical thread designs adapted to screw size and bone density provide secure screw engagement and resistance to pull-out

Indications

• Pubic symphysis diastasis

• Pelvic ring fractures involving the anterior arch

• Chronic instability or nonunion of the pubic symphysis

• Supplementary fixation following pelvic ring reduction

• Combined anterior and posterior pelvic trauma

Specifications
