The Distal Medial Tibial Universal Locking Plate is designed for internal fixation of distal tibial fractures, providing stable fixation and anatomical alignment.
The plate features 30° conical polyaxial locking holes, allowing screws to be positioned up to 15° from the hole axis in multiple directions. This provides flexibility in screw trajectory selection according to the fracture configuration.
Manufactured from TA3G pure titanium and TC4 titanium alloy, the plate provides mechanical strength, biocompatibility, and corrosion resistance. Its low-profile anatomical design, rounded edges, and polished surface help reduce soft tissue irritation.
• Polyaxial Locking Design: 30° conical locking holes allow multi-directional screw positioning within the permitted angulation range.
• Self-Tapping Screws: Sharp cutting edges facilitate screw insertion into the bone.
• Anodized Surface: Provides corrosion resistance and supports material durability and biocompatibility.
• Ball-Head Screw Design: Spherical screw heads engage with the locking holes to provide angular-stable fixation.
• Multiple Screw Sizes: Available screw diameters include 1.5 mm and 2.0 mm for smaller bone applications and 6.5 mm and 7.3 mm options for cancellous or osteoporotic bone.
• Low-Profile Plate: Anatomically contoured with rounded corners and a polished surface to help minimize soft tissue irritation.
• Flexible Screw Positioning: The polyaxial design allows screw angulation of up to 15°, providing flexibility for different fracture patterns and anatomical requirements.
• Stable Fixation: The locking screw interface creates a secure connection between the screws and plate.
• Rotational Stability: Multiple screw fixation can provide resistance to rotational movement within the fracture construct.
• Adaptation to Bone Conditions: Different screw sizes can be selected according to bone anatomy and bone quality.
• Simplified Polyaxial Fixation: The variable-angle locking function does not require additional inserts or auxiliary components.
• Adjustable Screw Trajectories: Screw direction can be selected according to the fracture location and required fixation position.
The Distal Medial Tibial Universal Locking Plate is indicated for internal fixation of:
• Distal tibial fractures
• Tibial plateau fractures
• Comminuted fractures
• Osteoporotic fractures
• Tibial shaft fractures
• Fractures involving the medial tibial region
• Intra-articular and extra-articular fractures
It is particularly applicable to fractures requiring polyaxial screw fixation or stable fixation in osteoporotic bone.
| Model Number | Spec.(mm) | Compatible screws |
| 4034014 | 4 Holes×72 Left | 2.7 mm Variable-Angle Locking Screw 2.7 mm Cortical Screw |
| 6 Holes×90 Left | ||
| 4 Holes×72 Right | ||
| 6 Holes×90 Right |
